Packaging Vibration Testing Equipment Runs Random Vibration Testing For Dummie

Packaging Vibration Testing Equipment Runs Random Vibration Testing For Dummie
Packaging Vibration Testing Equipment Runs Random Vibration Testing For Dummie Packaging Vibration Testing Equipment Runs Random Vibration Testing For Dummie Packaging Vibration Testing Equipment Runs Random Vibration Testing For Dummie Packaging Vibration Testing Equipment Runs Random Vibration Testing For Dummie

Large Image :  Packaging Vibration Testing Equipment Runs Random Vibration Testing For Dummie

Product Details:
Place of Origin: CHINA
Brand Name: PRECISION
Certification: CE
Model Number: VTS-10
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $6000
Packaging Details: Standard export packaging
Delivery Time: 15 working days
Payment Terms: T/T
Supply Ability: 100/month
Contact Now chat now
Detailed Product Description
Customized Support: OEM ODM Sine Force: 20kN
Random Force: 20kN Shock Force: 40kN
Frequency Range: 1-3000Hz Displacement: 76mm
Velocity: 2.0 Table Size: 1200x1200mm
Highlight:

Packaging Vibration Testing Equipment

,

Dummie Vibration Testing Equipment

,

Random Vibration Testing Equipment

Packaging Vibration Testing Equipment Runs Random Vibration Testing For Dummie
Customized support
OEM ODM
Sine force
20kN
Random force
20kN
Shock force
40kN
Frequency range
1-3000Hz
Displacement
76mm
Velocity
2.0
Table size
1200x1200mm
MIL-STD-810H Method 514.8 Vibration Testing Equipment

In product development and quality assurance, ensuring reliability under various environmental conditions is critical. Our electrodynamic shakers perform MIL-STD-810H Method 514.8 vibration testing, simulating real-world vibration scenarios to evaluate product durability across aerospace, defense, automotive, and consumer electronics industries.

Key Testing Capabilities
  • Simulates sinusoidal, random, and shock vibrations per MIL-STD-810H specifications
  • Identifies potential weaknesses in product designs before market release
  • Reduces field failures and associated recall costs
  • Accurate reproduction of complex vibration profiles (±0.1% frequency accuracy)
Packaging Vibration Testing Equipment Runs Random Vibration Testing For Dummie 0 Packaging Vibration Testing Equipment Runs Random Vibration Testing For Dummie 1
Technical Specifications
Specification Value
Rated Sine/Random/Shock Force 2,200 kgf/2,000 kgf/4,400 kgf
Frequency Range 5-3,000 Hz
Max. Displacement (p-p) 76 mm
Max. Velocity 2.0 m/s
Armature Diameter 340 mm
Max. Vertical Load Support 400 kg
Dimensions (LxWxH) 1,160 mm × 880 mm × 1,050 mm
Weight (Uncrated) 1700 kg
Industry Applications
Aerospace & Defense

Test avionics, navigation systems, and weapon components under flight vibration conditions to ensure mission-critical reliability.

Automotive

Evaluate engine mounts, transmissions, and electronic control units against road vibration profiles for durability validation.

Consumer Electronics

Verify smartphone, laptop, and tablet durability against transportation and daily-use vibration scenarios.

Packaging Vibration Testing Equipment Runs Random Vibration Testing For Dummie 2
Request Custom Vibration Testing Solutions

Our experts can provide electrodynamic shakers tailored to your specific MIL-STD-810H testing requirements. Contact us to discuss your product development and quality assurance needs.
