3 Axis Vibration Table Performs ISTA Vibration Testing ASTM D4728 Standard Compliant

3 Axis Vibration Table Performs ISTA Vibration Testing ASTM D4728 Standard Compliant
3 Axis Vibration Table Performs ISTA Vibration Testing ASTM D4728 Standard Compliant 3 Axis Vibration Table Performs ISTA Vibration Testing ASTM D4728 Standard Compliant 3 Axis Vibration Table Performs ISTA Vibration Testing ASTM D4728 Standard Compliant

Large Image :  3 Axis Vibration Table Performs ISTA Vibration Testing ASTM D4728 Standard Compliant

Product Details:
Place of Origin: CHINA
Brand Name: PRECISION
Certification: CE
Model Number: VTS-10
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $6000
Packaging Details: Standard export packaging
Delivery Time: 15 working days
Payment Terms: T/T
Supply Ability: 100/month
Contact Now
Detailed Product Description
Customized Support: OEM ODM Sine Force: 20kN
Random Force: 30kN Shock Force: 60kN
Frequency Range: 1-3000Hz Displacement: 100mm
Velocity: 2.0 Table Size: 1200x1200mm
Highlight:

ISTA Vibration Table

,

ASTM D4728 Vibration Table

,

3 Axis Vibration Table

3 Axis Vibration Table for ISTA Vibration Testing (ASTM D4728 Compliant)

Our advanced 3 Axis Vibration Table performs ISTA vibration testing in strict compliance with ASTM D4728 standard, providing reliable evaluation of packaged product durability during transit.

Key Specifications
Attribute Value
Customized support OEM ODM
Sine force 20kN
Random force 30kN
Shock force 60kN
Frequency range 1-3000Hz
Displacement 100mm
Velocity 2.0
Table size 1200x1200mm
Advanced Testing Capabilities
  • Tri-Axis Functionality: Simultaneously generates vibrations in X, Y, and Z axes for realistic transportation simulation
  • Precision Control: 1-3000Hz frequency range with ±50mm displacement and 100g acceleration
  • Standard Compliance: Fully calibrated to meet ASTM D4728 requirements for ISTA testing
  • Custom Test Profiles: Programmable parameters for frequency, amplitude, and duration
  • Robust Platform: 1200x1200mm high-strength surface with multiple attachment points
  • Intuitive Control: PC-based system with real-time monitoring and data logging
Detailed Technical Specifications
Parameter Value Parameter Value
Rated Sine/Random/Shock Force 3,000 kgf/3,000kgf/6,000 kgf Armature Mass 30 kg
Frequency Range 5-3,000 Hz Inserts Size (Standard) M10
Max./Continuous Displacement p-p 51 mm/51 mm Load Attachment Points 17
Max.Velocity 2.0 m/s Natural Frequency-Thrust Axis <3Hz
Max.Sine/Random Acceleration 100/60g Max. Vertical Load Support 500 kg
Industry Applications
  • Consumer Goods: Electronics, glassware, and food product packaging testing
  • Industrial Products: Machinery parts, chemicals, and automotive components
  • E-commerce Packaging: Ensuring fragile items survive shipping conditions
3 Axis Vibration Table Performs ISTA Vibration Testing ASTM D4728 Standard Compliant 0 3 Axis Vibration Table Performs ISTA Vibration Testing ASTM D4728 Standard Compliant 1

Our 3 Axis Vibration Table provides comprehensive ASTM D4728-compliant testing to improve packaging quality, reduce product damage, and optimize supply chain efficiency. Contact us to discuss custom testing solutions for your specific requirements.
