40kN Vibration Shaker Runs ISTA 3A Vibration Test For Pallet Goods

Large Image : 40kN Vibration Shaker Runs ISTA 3A Vibration Test For Pallet Goods

Product Details:

Place of Origin:	CHINA
Brand Name:	PRECISION
Certification:	CE
Model Number:	VTS-40

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$6000
Packaging Details:	Standard export packaging
Delivery Time:	15 working days
Payment Terms:	T/T
Supply Ability:	100/month

Contact Now

Detailed Product Description

Customized Support:	OEM ODM	Sine Force:	40kN
Random Force:	40kN	Shock Force:	80kN
Frequency Range:	1-3000Hz	Displacement:	100mm
Velocity:	2.0	Table Size:	1500x1500mm
Highlight:	40kN Vibration Shaker , Pallet Goods Vibration Shaker , ISTA 3A Vibration Shaker

40kN Vibration Shaker for ISTA 3A Vibration Testing of Pallet Goods

In logistics and supply chain management, ensuring safe transit of palletized goods is critical. Our high-performance 40kN Vibration Shaker is engineered specifically for ISTA 3A vibration testing of pallet goods, providing a reliable solution for evaluating package integrity during transportation.

Key Specifications

Customized support	OEM ODM
Sine force	40kN
Random force	40kN
Shock force	80kN
Frequency range	1-3000Hz
Displacement	100mm
Velocity	2.0
Table size	1500x1500mm

ISTA 3A Testing Importance

The ISTA 3A test protocol simulates vibrations, shocks, and handling that palletized goods encounter during distribution. Testing helps identify packaging weaknesses, reduce product damage, minimize returns, and maintain customer satisfaction.

Product Features

High-Capacity Vibration: 40kN force output with frequency range of 1-3000Hz for comprehensive testing scenarios
Large Test Platform: 1500x1500mm surface accommodates standard pallets with actual packaging configurations
ISTA 3A Compliance: Precisely calibrated to meet all standard requirements for pallet testing
User-Friendly Controls: PC-based system with intuitive software for parameter input and real-time monitoring
Durable Construction: High-quality materials withstand continuous use in demanding testing environments

Technical Specifications

Specification	Value
Rated Sine/Random/Shock Force	4,000 kgf/4,000kgf/8,000 kgf
Frequency Range	5-3,000 Hz
Max. Displacement p-p	100 mm
Max. Velocity	2.0m/s
Armature Diameter	440 mm
Max. Vertical Load Support	500 kg
Dimensions (L x W x H)	1,270 mm x 980mm x 1,135mm
Weight (Uncrated)	2,500 kg

Applications

Logistics Companies

Pre-test pallet shipments to identify packaging issues before dispatch, reducing transit damage and associated costs.

Manufacturing Companies

Optimize packaging design by testing materials, cushioning methods, and pallet fastening techniques for safer product delivery.

Our 40kN Vibration Shaker offers a comprehensive solution for ISTA 3A testing of pallet goods, combining high-capacity performance with user-friendly operation and durable construction for reliable long-term use.
