Custom Vibration Climate Chamber For EV Cells Electric Vehicle Component

Large Image : Custom Vibration Climate Chamber For EV Cells Electric Vehicle Component

Product Details:

Place of Origin:	CHINA
Brand Name:	PRECISION
Certification:	ISO
Model Number:	VTHC-225

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$6000
Packaging Details:	Standard export packaging
Delivery Time:	15 working days
Payment Terms:	T/T
Supply Ability:	100/month

Contact Now

Detailed Product Description

Customized Support:	OEM ODM	Origin:	China
Material:	Stainless Steel	Controller:	Programmable LCD Touch Screen
Temp Accuracy::	0.5°C	Temp Uniformity:	0.5°C
Refrigerant:	Environmental Friendly R23/R404	Vibration Force:	2000kg.f(20kN)
Temp. Range:	-60°C To +180°C	Humdity Range:	10% To 98%
Highlight:	Electric Vehicle Component Climate Chamber , EV Cells Climate Chamber , Custom Climate Chamber

Custom Vibration Climate Chamber For EV Cells Electric Vehicle Component

Attribute	Value
Customized support	OEM ODM
Origin	China
Material	Stainless Steel
Controller	Programmable LCD Touch Screen
Temp accuracy	0.5°C
Temp uniformity	0.5°C
Refrigerant	Environmental friendly R23/R404
Vibration force	2000kg.f(20kN)
Temp. range	-60°C to +180°C
Humidity range	10% to 98%

Custom Climate Chamber with Vibration Test for EV Cells, Modules and Packs

In the rapidly evolving electric vehicle (EV) industry, our Custom Climate Chamber with Vibration Test provides a cutting-edge solution for testing battery components under various environmental and mechanical conditions. Designed for EV manufacturers, research institutions, and testing laboratories, this chamber evaluates durability, safety, and performance while ensuring compliance with industry standards.

Key Features and Benefits

Robust Construction: Heavy-duty steel frame with insulated walls for strength and temperature stability
Precision Control: Advanced temperature (-60°C to +180°C) and humidity (10% to 98% RH) systems with ±0.5°C accuracy
Vibration Testing: 20kN vibration force capability to simulate real-world driving conditions
User-Friendly Interface: Programmable LCD touch screen controller for easy operation
Comprehensive Safety: Multiple protection systems including over-temperature and emergency stop features
Data Acquisition: Integrated system for recording and exporting test results

Technical Specifications

Temperature Range: -60°C to +180°C with ±0.5°C accuracy
Humidity Range: 10% to 98% RH
Vibration Force: 2000kg.f (20kN)
Construction: Stainless steel with environmental-friendly R23/R404 refrigerant
Control System: Programmable LCD touch screen interface

Applications

This chamber is specifically designed for testing EV battery cells, modules, and packs under combined environmental and vibration stresses. It enables manufacturers to:

Evaluate battery performance in extreme temperature conditions
Test durability against vibration stresses encountered during vehicle operation
Assess long-term reliability through accelerated aging tests
Verify compliance with international automotive testing standards
